10G SFP+ to SFP+ Fiber to Fiber Media Converter - 10G OEO 3R Transparent Repeater - 2 x Standard Open SFP+ Slots - Universal - Supports 10GB SFP+ Fiber and Copper Modules - Without Transceivers

10G SFP+ to SFP+ fiber to fiber converter is a fiber-to-fiber type 10Gbps device that acts not only as fiber optic media converter or as a fiber optic repeater for long-haul transmission, but is an all in one solution to get 10GE fiber network to be Re-Amplificated, Re-Shaped and Re-Timed. 3R Repeater / Extender / Media converter for all your 10G fiber network mode & wavelength conversion needs. More than that - unit supports 10G SFP+ type modules It is commonly used in network backbones (SAN, LAN, MAN, WAN). Supports various protocols such as SDH / SONET STM-64 / OC-192, 10G Fiber Channel, 10G Ethernet, etc. can be used in a telecommunications room, R&D lab, data center, etc. Supports any standard SFP+ 10G 850nm, 1310nm / 1550nm / CWDM / DWDM optical wavelength conversion. Product featuresJumbo frames supportTransparent signal transmission and low latencyThe rate supports 8.5Gbps~11.7Gbps Supports OEO 3R functions: signal amplification and regeneration, waveform shaping, clock retimingEasy installation - Plug & PlayWide Range Protocol Support 8.5G Fiber Channel SONET OC-192, SDH STM-64 (9.95Gbps) 10G WAN (10Gbps) 10G LAN (10.31Gbps) OTN OTU-2 (G.709) (10.70Gbps) 10G LAN with 255/237 FEC coding (11.09Gbps) 10G Fiber Channel (11.32Gbps) 10G POS Technical ParametersTransmission rate:8.5Gb/s-11.7Gb/sInterface Type: SFP+ standard slotPower supply input voltage:DC 12V (AC adapter comes in set)Power consumption:≤4WOperating temperature:0-℃~60℃Size (L*W*H):110mm(L)*100mm(W)*30mm

• Use it as a Single to Multimode Media Converter - 2 X standard open SFP+/SFP slots for any type of SFP+ modules
• Use it as a Single Mode Dual Fiber to Single Mode Single Fiber Converter - thus, saving the fibers!
• Use it as a 3R - Re-amplification, Re-shaping And Re-timing Device - Signal Repeater & Converter, all in the same box!
• Use it for converting & matching wavelengths when interconnecting third party 10Gbps network devices - i.e. 850 nm to 1300/1310 nm, 1310 nm to 1550 nm, even DWDM and CDWM wavelengths are supported. Just find the correct and matching SFPs for both slots!
• Wide range of protocols supported: 10G Ethernet, 10G WAN (10Gbps), 10G LAN (10.31Gbps), 8.5G Fiber Channel, 10G LAN with 255/237 FEC coding (11.09Gbps) and more!
