6KW air-cooled spindle motor 380V 220V 18000rpm chuck ER32 4 pieces bearing GDF120-102-6.0(6.0kw ER32 380V)
4.0 (90 items)
Limited Time SaleUS$883.55 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211269960 | Release Date | 2026/04/04 | List Price | US$589.03 | Model Number | 211269960 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Slotting Cutter ArborsModel: GDF120-102-6.0Speed regulation method: Change the spindle speed through the three-phase output inverter and adjust the frequency of the inverter.Cooling method: air coolingPower interface: An optional 5-pin waterproof aviation connector is marked with "1", "2", "3", "4", "5", and "GND". "1", "2", and "3" are connected to the inverter (U, V, W) respectively, and "GND" is connected to the inverter ground.(Note! Our spindle "4" is connected to GND for personal safety!!)Power: 6.0kw (1HP=0.735w)Voltage: 220V 380VCurrent: 16AFrequency: 0-300HzSpeed: 0-18000rpmJump: less than 0.01mmBearing type: 2*7008C P4, 2*7002C P4 (4 ball bearings)Chuck: ER32Clamping tool diameter: 1mm, 2mm, 3mm, 3.175mm (1/8), 4mm, 5mm, 6mm, 6.35mm (1/4), 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 12.7mm (1/2), 13mm, 14mm, 15mm, 16mm, 17mm, 18mm, 19mm, 20mm
- Slotting Cutter Arbors
| Size | 6.0kw ER32 380V |
|---|---|
| Color | With Flange |
| Item Weight | 5.8 ounces |
| Part Number | LKBEJMYY |
| Manufacturer | LKBEJMYY |
| Number Of Pieces | 1 |
| Item model number | LKBEJMYY |
| Package Dimensions | 4.33 x 4.33 x 4.33 inches |
| Item Package Quantity | 1 |
